Ø22 Super flush dot illuminated
The R.series is a range of vandal-resistant pushbuttons that are designed to improve the durability and strength of control panels.
These pushbuttons are protected to IK10 and IP65, which makes them ideal for use in exposed public areas or aggressive industrial environments.
The R.series pushbutton are available with LED illumination, either an attractive 'halo' ring or central dot.
The halo effect creates a stylish, contemporary look that is also an effective way to focus the user's attention on a primary function.

Different versions available:

  • Ø22
  • Illuminated dot
  • Lighting colour: blue, red, green and other colours on request
  • Materials: Stainless steel
  • Flush actuator
  • Switching: 1NO / 1NC
  • Pin terminal



TYPICAL APPLICATIONS
  • Access control, security systems
  • Exposed public areas: ticketing machines, vending machines, kiosks
  • Industrial: machinery and factory equipment..
ELECTRICAL CHARACTERISTICS
  • Switching rate:
    • 5A / 250VAC
  • Electrical life (full load):
    • 50 000 cycles
  • Insulation resistance
    • > 1000 MΩ
  • Contact resistance:
    • ≤ 50 mΩ
  • Dielectric strength
    • 2000 VAC
  • LED Life
    • 40 000 Hours

ENVIRONMENTAL CHARACTERISTICS
  • Temperature:
    • Operating -20°C to +55°C
  • Vandal resistance:
    • Impact resistant to IK10
    • Sealed to IP65
  • RoHs

MECHANICAL CHARACTERISTICS
  • Actuating force
    • ≈ 5.5N
  • Mechanical lifetime
    • 1 million of cycles

SWITCHING SYSTEM
  • Contact arrangement:
    • 1 NO (Normally Open and 1 NC (Normally Closed)
  • Function:
    • Momentary
  • Terminals:
    • Pin terminal 2.8mm x 0.5mm


STANDARD PART NUMBERS
On the references below replace the symbol ""› by the colour code of the following Table 1.1 LED and symbol "" by the rated voltage following Table 1.2

Table 1.1: Symbol ""
R = RED      G = Green      B = Blue
"other colours on request"


Table 1.2: Symbol ""
6 = 6V   /  12 = 12V  /  24 = 24V  /  110 = 110V /  220 =220V
"other colours on request"

Example: Pushbutton R22FFSSPAGDB24 Ø22 blue illuminated ring 24V

PIN TERMINAL (2.8mm x 0.5mm)


Technical datasheet R22 super flush dot illuminated
